GM
ENERPAT
| Quantity: | |
|---|---|
| ENERPAT Granulator The Enerpat GM Series granulator is a high-performance device known for its high torque, low energy consumption, and low noise characteristics, specifically designed for material recycling and processing. This machine is suitable for handling low-hardness, brittle, and ductile materials, including but not limited to plastic products such as PP, PE, PET, PVC, rubber products, and other non-metallic waste materials. By replacing screens of different sizes, users can flexibly adjust the particle size of the final crushed products to meet diverse requirements. |
Operating Principle
Material Conveying
Materials are transported to the grinding chamber of the grinder.
Material Crushing
Materials are crushed through the shearing action between the internally rotating high-speed knife rollers and the stationary blades.
Receiving Hopper Discharge
Once the crushed materials are smaller than the diameter of the screen holes, they fall into the receiving hopper.
Product Specification Sheet
| Model | GM-600S | GM-800S | GM-800L | GM-1000S |
| Motor Power(kW) | 22 | 30 | 37 | 55 |
| Machine Size(mm) | 1438×1177×2197 | 1440×1377×2197 | 1637×1450×2272 | 1858×1648×2071 |
| Shredding Chamber Length(mm) | 620 | 820 | 820 | 1020 |
| Shaft Diameter(mm) | φ320 | φ320 | φ420 | φ420 |
| Shaft Speed(rpm) | 580 | 580 | 580 | 580 |
| Counter Knives(pcs) | 2 | 2 | 2 | 4 |
| Rotor Knives(pcs) | 6 | 6 | 6 | 6 |
| Screen Quantity(pcs) | 1 | 1 | 1 | 1 |
| Screen Mesh Size(mm) | φ12 | φ12 | φ12 | φ12 |
| Model | GM-1200S | GM-1600S | GM-2500S |
| Motor Power(kW) | 75 | 132 | 132+132 |
| Machine Size(mm) | 2155×2202×3141 | 2470×2600×3373 | 2881×3942×4397 |
| Shredding Chamber Length(mm) | 1220 | 1600 | 2500 |
| Shaft Diameter(mm) | φ520 | φ660 | φ800 |
| Shaft Speed(rpm) | 520 | 520 | 460 |
| Counter Knives(pcs) | 4+2 | 4+2 | 4+2 |
| Rotor Knives(pcs) | 10 | 28 | 45 |
| Screen Quantity(pcs) | 1 | 1 | 1 |
| Screen Mesh Size(mm) | φ12 | φ20 | φ20 |
Material Testing
The ENERPAT granulator performs reliably under high-load conditions. The sides of the box are equipped with standard wear-resistant plates, and additional wear-resistant components can be installed in other key areas of the housing. Wear-resistant layers can also be welded around the knife rollers and stationary blades, ensuring that this series is better suited for crushing materials that can cause equipment wear, such as shattered fiberglass and sand-containing films.
Ryan Jang
"The ENERPAT granulator plays a crucial role in our plastic products production line. It significantly enhances the waste recycling rate, and the quality of the produced granules is excellent, allowing them to be directly used for re-manufacturing. The operation is simple, and maintenance is convenient, truly enabling efficient resource recycling and lowering our production costs."
Ignacio Ramos
"Since introducing the ENERPAT granulator, our recycling company's processing capacity has significantly improved. This machine efficiently handles various types of waste plastics, transforming them into high-quality regranulated materials. The equipment operates stably, produces low noise, and is easy to maintain, providing us with substantial economic and environmental benefits. The ENERPAT industrial plastic grinder is truly reliable!"
